Relieving the pressure of your daily work.

ValvePilot – Easy Valve Selection

The easy and clearly arranged calculation and design software for self-acting control valves will relieve the pressure of your daily work because, among other things, the design of the valve parameters is considerably simplified.

VERSIONS

Desktop-Version

COMPARE THE VERSIONS

Online-Version

Calculation and design software for self-acting control valves (pressure reducing valves / back pressure regulators) incl. classification in accordance with PED

Features

CALCULATIONS

Warnings, recommendations, notices

DATA STORAGE

PERSONALIZation

INTEGRATED HELPER FUNCTIONS

VALVE PRE-SELECTION

Calculations are based on the following standards

»  ANSI / ISA-75.01.01 (IEC 60534-2-1 Mod) -2007

»  ASME B36.10M-2004

»  IEC-Aerodynamic 60534-8-3 (for gases 2010-11), IEC-Hydrodynamic 60534-8-4 (for liquids 2005-08)

CALCULATIONS

DETAIL OVERVIEW

»  KV, KVS und CVS Values (KVS = KV plus 30% security)

»  Valve inflow and outflow velocity

»  Connection size (flange/thread size)

»  Noise emission

»  Flow velocity upstream and downstream of the valve

»  Saturated steam temperature

»  Display of material properties (database with more than 50 media and their properties (can be customized in the "Expert Plus Mode"))

»  Possibility to change the measurement units, the programme will automatically convert the values

»  Reduction ratio

Warnings, recommendations, notices

»  Phase changeover

»  Cavitation

»  Noise pressure level (seperate noise pressure level rating for liquids and gases according to IEC-Aerodynamic 60534-8-3 (for Gases 2010-11),
    IEC-Hydrodynamic 60534-8-4 (for liquids 2005-08))

»  Recommended pipe extension

»  Hard-facing of cone / seat (recommendation as per internal guideline by Mankenberg GmbH)

»  Pressure loss calculation after selection of the valve (for an idealised 10 m long pipeline section downstream of the valve)

»  Flow velocity exceeding velocity limits

DATA STORAGE (ONLY AVAILABLE IN THE DOWNLOAD-VERSION)

»  Several designs can be stored as a project

»  Stored projects can be retrieved as a revision

»  Revisions can be compared to each other

PERSONALIZation (ONLY IN THE DOWNLOAD VERSION available)

»  Name, company etc.

»  Units

»  Noise pressure level limit

INTEGRATED HELPER FUNCTIONS

»  Flange helper, depending on temperature, pressure, nominal diameter and material (as per DIN, JIS, ASME)

»  PED categorisation incl. article description

»  Selection of the optimal safety valve size (response pressure, KV value)

»  Valve is ranged into its operating characteristic diagram (graph)

EXPORT

»  Data export (CSV format)

»  Detailed results log (PDF format, as per the technical data sheet)

VALVE PRE-SELECTION*

»  Can be filtered according to material, connections and elastomers

»  Article description and application area

»  Flow velocity incl. pressure loss can be checked after the valve has been selected





*from the standard range of Mankenberg GmbH

All rights reserved, all indications without engagement, subject to modifications.

No liability is assumed for the correctness or completeness of the calculated design data.

In addition to the easy and comfortable determination of the KV, KVS and CVS values,
ValvePilot also calculates further useful values such as:

»  Noise pressure level

»  Nominal diameter

»  Inflow and outflow velocity

»  Reduction ratio



Moreover, ValvePilot provides warnings or recommendations for problematic
designs and offers helper functions that simplify the way to find the suitable valve.
